System with floor spreader
Payload 3kg / 6.6lb

  • RC-30

System components
Head: H15 Tripod: RT30B
Spreader: SP-2B Case: RC-30
Operation manual
H15 RT30B
SP-2B
Specification sheet
HS-150 H15
RT30B SP-2B
RC-30
Service parts
H15 RT30B
SP-2B
Specifications
Counterbalance range 0.8 to 2kg / 1.7 to 4.4lb (C.G.55mm)
Payload 3kg / 6.6lb
Counterbalance Perfect Balance
Continuous Counterbalance with Illuminated Meter
Drag mode Free plus 3 steps
Drag system Multilayered Metal Structure
Tilt angle +90° / -70°
Temperature range -40°C to +60°C / -40°F to +140°F
Bubble level Illuminated
Camera plate Sliding plate compatible
with Manfrotto and Sachtler heads
Sliding range +/-30mm / 1.2"
Long sliding plate Optional
Head base 75mm ball / Flat base
Plate attachment 1/4" screw with video pin
Accessory attachments 1/4" and 3/8" screw holes
Spare screw 1/4" and 3/8" screws
Weight 6.2kg / 13.7lb
Height 56 to 166cm / 22 to 65.4"
Head attachment 75mm bowl
Pipe material Aluminium
Section 2-Stage
H15 Counterbalance chart
